23AWG CAT6A FFTP 10GBPS HIGH SPEED DATA CENTER INDUSTRIAL NETWORK CABLE SOLID COPPER
Product Description:
Engineered for performance, this CAT6A FFTP Cable from ITI-LINK enables 10Gbps transmission with robust shielding and Solid Copper wires. The Shielded LAN Cable with LSZH jacket minimizes noise for superior network stability. A premium Data Center Cable and Industrial Network Cable solution for 5G, enterprise, and power installations.
① Reliable 10Gbps Speed:
Delivering consistent 10Gbps throughput, the ITI-LINK CAT6A FFTP Cable ensures high network efficiency for demanding applications including video streaming, cloud services, and large file transfers.
② Superior Shielding Technology:
The FFTP foil shield and pair shielding protect your connection from outside noise, improving performance for both short and long runs in harsh environments.
③ Premium Materials:
Copper-rich construction with Solid Copper conductors ensures optimal conductivity and minimal signal loss. The Shielded LAN Cable also features a robust jacket with LSZH for enhanced safety.
④ Industrial & Commercial Ready:
Perfect choice for Industrial Network Cable deployments, office networks, manufacturing automation systems, and structured cabling in commercial buildings.
⑤ Enhanced Safety & Compliance:
The LSZH jacket minimizes toxic emissions under heat or flame, delivering peace of mind for critical infrastructure and regulatory compliance.
Technical Parameters:
| Electrical Properties |
| Conductor Resistance at 20°C |
NF EN 50289-1-2 / IEC 60189-1 |
≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair |
NF EN 50289-1-2/ IEC 60708 |
≤ 5% |
|
Dielectric Strength
Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min
|
NF EN 50289-1-3 / IEC 61196-1-105
|
No breakdown
|
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V |
NF EN 50289-1-4 / IEC 60885-1
|
>1500 MΩ / 100m |
| Mutual capacitance |
NF EN 50289-1-5 /IEC 60189-1 |
5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz |
NF EN 50289-1-5 / IEC 60189-1 |
≤ 160 pF / 100m |
| Characteristic impedance at 100MHz |
NF EN 50289-1-11/ IEC 61156-1 |
100 ± 15 Ω |
| Spark Test |
UL444 |
2000 ± 250VOC |
| Transmission Properties |
| CAT6A F/FTP |
|
No.
|
Frequency
|
Attenuation (Max)
|
Propagation Delay
(Max)
|
Propagation Delay Skew
(Max)
|
Return Loss (Min)
|
NEXT (Min)
|
PS NEXT (Min)
|
EL-FEXT (Min)
|
PS EL-FEXT (Min)
|
| MHz |
dB/100m |
ns/100m |
ns/100m |
dB(on 100m) |
dB(on 100m) |
dB(on 100m) |
dB(on 100m) |
dB(on 100m) |
| 1 |
4 |
3.8 |
552 |
45 |
23.01 |
66.27 |
63.27 |
55.96 |
52.96 |
| 2 |
8 |
5.31 |
546.73 |
45 |
24.52 |
61.75 |
58.75 |
49.94 |
46.94 |
| 3 |
10 |
5.93 |
545.38 |
45 |
25 |
60.3 |
57.3 |
48 |
45 |
| 4 |
16 |
7.49 |
543 |
45 |
25 |
57.24 |
54.24 |
43.92 |
40.92 |
| 5 |
20 |
8.38 |
542.05 |
45 |
25 |
55.78 |
52.78 |
41.98 |
38.98 |
| 6 |
25 |
9.38 |
541.2 |
45 |
24.32 |
54.33 |
51.33 |
40.04 |
37.04 |
| 7 |
31.25 |
10.5 |
540.44 |
45 |
23.64 |
52.88 |
49.88 |
38.1 |
35.1 |
| 8 |
50 |
13.36 |
539.09 |
45 |
22.21 |
49.82 |
46.82 |
34.02 |
31.02 |
| 9 |
62.5 |
14.99 |
538.55 |
45 |
21.54 |
48.36 |
45.36 |
32.08 |
29.08 |
| 10 |
100 |
19.13 |
537.6 |
45 |
20.11 |
45.3 |
42.3 |
28 |
25 |
| 11 |
125 |
21.51 |
537.22 |
45 |
19.43 |
43.85 |
40.85 |
26.06 |
23.06 |
| 12 |
200 |
27.58 |
536.55 |
45 |
18 |
40.78 |
37.78 |
21.98 |
18.98 |
| 13 |
250 |
31.07 |
536.28 |
45 |
17.32 |
39.33 |
36.33 |
20.04 |
17.04 |
| 14 |
300 |
34.27 |
536.08 |
45 |
17.3 |
38.14 |
35.14 |
18.46 |
15.46 |
| 15 |
350 |
37.25 |
535.92 |
45 |
17.3 |
37.14 |
34.14 |
17.12 |
14.12 |
| 16 |
400 |
40.05 |
535.8 |
45 |
17.3 |
36.27 |
33.27 |
15.96 |
12.96 |
| 17 |
450 |
42.71 |
535.7 |
45 |
17.3 |
35.5 |
32.5 |
14.94 |
11.94 |
| 18 |
500 |
45.26 |
535.61 |
45 |
17.3 |
34.82 |
31.82 |
14.02 |
11.02 |
Applications:
-
High-density server farms and Data Center Cable deployments
-
Industrial Network Cable for robotics and manufacturing systems
-
Shielded LAN Cable for electrical installations
-
5G Base Station connections
-
Commercial building network infrastructure
